Flush-mounting “Top Entry” ball valve with flush control accessories
THE LEADER IN FLUSH MOUNTING SINCE 1987
Ultra is the perfect blend of accessibility and aesthetic appeal. Its flush design combines technology and functionality to minimise protrusion and maximise the look.
Flush accessories make Ultra the ideal shut-off valve for modern bathrooms and kitchens with sophisticated, geometric lines, as well those with a clean, traditional look.
Ultra fits in anywhere without interfering with the harmony of the stylistic choices in interior spaces. Available in four finishes, it adapts to the most modern colour combinations and matches the decor, giving a feeling of completeness to the room.
Product range
ULTRA threaded / FASTEC version
ULTRA "U" FASTEC Version
ULTRA version for PP-R pipes
Specifications
"TOP ENTRY” REMOVABLE BALL
Specifications
"TOP ENTRY” REMOVABLE BALL
“Soft turn” anti-jamming ball valve
MAXIMUM CONTROL
ULTRA and 164 valves are equipped with a shut-off assembly,
which ensures a low operating torque that remains constant
over time, thanks to “Soft Turn” technology. The combination
of the engineered polymer ball and specially designed seals
ensures correct operation , even in the event of an emergency or
when carrying out maintenance on the system.
- The PPSU (engineered polymer) balls combined with the seals prevent adhesion of limescale and formation of deposits that could lead to jamming. These features ensure optimal operation even after long periods of inactivity without the need for periodic activation
- Resistance to abrasion by impurities (sand).
- 100% compatible with drinking water.
- No water stagnation (DIN 13828 / W570-1).
- Chlorine resistant.
Design and finiture
White
Polished Chrome
Silver
Black Soft Touch
Frame with aesthetic and/or remedy function
The frames available for the ULTRA flush-mounting valves can:
- offer multiple colour combinations to suit various environment styles.
- cover any imperfections in claddings.
Technical data
APPLICATIONS
- For hot and cold drinking water.
- For cooling and heating water with or without antifreeze.
- For masonry and plasterboard constructions.
- For compressed air.
| Technical data | |
|---|---|
| Standard and certification | DIN EN 13828 W570-1 KTW-BWGL ACS PZH |
| Pressure | PN 10 (10 bar) |
| Temperature | +5 °C ÷ +95 °C PP-R version +70 °C |
| Fittings | FASTEC® EN 10226-1 R/Rp thread Multi-clamp (multi-layer pipes) PP-R (PP-R pipes) |
 Patented | |
FEATURES
- Flush-mounting water shut-off ball valves.
- “Soft Turn” anti-jamming technology to ensure jam-free operation even after long periods of inactivity without the need for periodic activation.
- "Top Entry": ball and seals can be replaced after the valve has been installed.
- Full-flow ball, DN 15-20-25.
- Internal rinsing system that prevents dangerous water stagnation in accordance with the strict German legionella regulations.
- The ULTRA range adapts to the installation depth with the need for extensions.
- Wide range of control accessories that integrate into the design of the environment.
- Different connection types: FASTEC® - threaded - with multilayer connections - for PP-R pipes.
Documentation
Teco offers its product libraries developed on the Autodesk Revit platform, ensuring data compliant with BIM standards.
BIM Catalogue
